F12 Series Parker Axial Piston Fixed Motors Large Frame

Body Material: Cast Iron

Circuit Type: Open

Fluid Type: Standard Hydraulic Fluid

Maximum Displacement (Cm3/Rev): 242 (Cm3/Rev)

Maximum Displacement (In3/Rev): 14.76

Maximum Flow (Gpm): 95.83

Maximum Flow (Lpm): 363 Lpm

Maximum Fluid Temperature (c): 115 Degrees

Maximum Fluid Temperature (f): 239

Minimum Fluid Temperature (c): - 40 Degrees

Minimum Fluid Temperature (f): -40

Maximum Noise Level (Dba): 88 Dba

Maximum Operating Pressure (Bar): 480 Bar

Maximum Operating Pressure (Psi): 6960

Maximum Speed (Rpm): 3150 Rpm

Maximum Viscosity (Sus): 1000 Cst /4664 Sus

Minimum Viscosity (Sus): 8 Cst/ 37.3 Sus

Maximum Weight (Kg): 77 Kg

Maximum Weight (Lbs): 169.4

Pump Technology: Piston

Pump Type: Fixed

Parker Axial Piston Fixed Motors F12 Series Features/Benefits

- Displacement from 30-250 cc – support various applications.

- Gear synchronization – robust and reliable

- High overall efficiency – reducing greenhouse gas emissions and fuel consumption.

- Low noise level – meeting industry noise emissions.

- Low weight – reducing greenhouse gas emissions and fuel consumption.

- Laminated piston rings –- low internal leakage, high overall efficiency

- High speed capability – suitable for a variety of applications

- Operating pressures up to 480 bar

- Shaft end and mounting flange meet ISO, SAE and Cartridge standards.

- Small installation dimensions – fits wide range of applications.

- Tolerates low and high temperature shocks –- suitable for the most demanding environments.
